Low Carbon Ferrochrome Electric Refining Tilting Furnace FeCr Alloy Smelting Production Line
| Place of Origin | Shaanxi, China |
|---|---|
| Brand Name | Shaanxi Chengda |
| Certification | ISO9001 |
| Model Number | Negotiate based on equipment processing capacity |
| Minimum Order Quantity | 1 set |
| Price | To be negotiable |
| Packaging Details | Discuss according to the specific requirements of Party A |
| Delivery Time | 2~3 months |
| Payment Terms | T/T,Western Union,,D/A |
| Supply Ability | Complete production supply chain, supply on time, and meet quality standards |
Product Details
| Rated Transformer Capacity | 3000 KVA (customizable) | Furnace Type | Tilting Electric Refining Furnace |
|---|---|---|---|
| Refining Process | Electro-silicothermic Refining | Max Tilting Angle | 0-45 Degrees |
| Electrode Regulation | PLC Automatic Control | Cooling System | Closed Loop Water Cooling |
| Carbon Content Control | Low Carbon FeCr C<=0.5%, Micro Carbon FeCr C<=0.1% | ||
| Highlight | low carbon ferrochrome smelting furnace,tilting furnace for FeCr alloy,ferroalloy refining production line |
||
Product Description
1. Overview of the Low Carbon Ferrochrome Refining Furnace
The low carbon ferrochrome refining electric furnace is a tilting-type refining unit specially designed for the electro-silicothermic production of low carbon and micro carbon ferrochrome. It refines high carbon ferrochrome melts with chromium ore and lime under a reducing atmosphere, effectively lowering the carbon content while protecting chromium recovery. The furnace is widely applied in ferroalloy plants for producing low carbon ferrochrome (C<=0.5%) and micro carbon ferrochrome (C<=0.1%) with stable alloy quality.
2. Main Structure and Components
The refining furnace mainly consists of the tilting furnace shell, refractory lining, three-phase electrode system, transformer and high current supply, hydraulic tilting device, water cooling system, electrode lifting mechanism, feeding system and PLC automatic control system. The compact layout saves plant floor space and simplifies operation for continuous refining campaigns.
3. Key Features
- Electro-silicothermic refining process for low carbon and micro carbon ferrochrome production
- Hydraulic tilting mechanism with large tapping angle for smooth slag-metal separation
- Water-cooled furnace shell and electrode holders for extended service life
- PLC based automatic electrode regulation and temperature control
- Reliable transformer and short network design for stable refining power input
- Low carbon content control and high chromium recovery rate
4. Technical Parameters
| Rated Transformer Capacity | 3000 kVA (customizable) |
| Furnace Type | Tilting electric refining furnace |
| Refining Process | Electro-silicothermic refining for low carbon ferrochrome |
| Max Tilting Angle | 0-45 degrees (customizable) |
| Electrode System | Three-phase electrode with PLC regulation |
| Cooling System | Closed loop water cooling |
| Annual Production Capacity | Customized according to plant design |
5. Application
The furnace is suitable for ferroalloy enterprises producing low carbon and micro carbon ferrochrome used as alloy additives in stainless steel and special steel smelting. We provide complete engineering design, equipment manufacturing, installation and commissioning service.
