Blast Furnace Hot Molten Slag Holding Furnace for Rock Wool Mineral Wool Production Line
| Place of Origin | Henan, China |
|---|---|
| Brand Name | ECER |
| Certification | ISO 9001:2015, CE |
| Model Number | BFSH-30T |
| Minimum Order Quantity | 1 Set |
| Price | USD 300,000-600,000 / Set |
| Packaging Details | Standard export packing with steel frame and waterproof covering |
| Delivery Time | 60 days after down payment |
| Payment Terms | T/T,L/C |
| Supply Ability | 2 Sets per Month |
Product Details
| Holding Capacity | 30 Tons | Holding Temperature | 1450-1550 Deg C |
|---|---|---|---|
| Heating Method | Electric Resistance / Electrode Heating | Rated Power | 2500 KW |
| Lining Material | High Alumina Refractory | Discharge Method | Hydraulic Tilting |
| Control System | PLC Temperature Control | Application | Rock Wool / Mineral Wool Production |
| Highlight | blast furnace slag holding furnace,rock wool production electric furnace,mineral wool molten slag furnace |
||
Product Description
Blast Furnace Hot Molten Slag Holding Furnace
Overview: This blast furnace hot molten slag holding furnace is purpose-built for rock wool and mineral wool production lines. It receives and holds 1450-1550°C molten slag directly from the blast furnace, maintaining stable temperature and fluidity so the slag can be continuously fed to the fiberizing process. The furnace maximizes utilization of blast furnace waste heat and turns molten slag into high-value rock wool products.
Key Features
- Direct holding of blast furnace hot molten slag without re-melting energy loss
- Stable slag temperature control ensuring consistent fiberizing quality
- Electric electrode heating backup for temperature compensation
- Hydraulic tilting discharge with adjustable slag flow rate
- High alumina refractory lining with long service life
- PLC temperature control system with remote monitoring
Technical Parameters
| Holding Capacity | 30 Tons |
| Holding Temperature | 1450-1550 °C |
| Heating Method | Electric Resistance / Electrode Heating |
| Rated Power | 2500 kW |
| Lining Material | High Alumina Refractory |
| Discharge Method | Hydraulic Tilting |
| Control System | PLC Temperature Control |
| Application | Rock Wool / Mineral Wool Production |
Applications
Widely used in rock wool, mineral wool and slag wool production plants that utilize blast furnace molten slag as the main raw material, delivering significant energy and cost savings.
Why Choose Us
- Customized design based on blast furnace slag output and temperature
- Complete engineering, installation and commissioning service
- ISO 9001:2015 certified manufacturing with strict quality control
