DCS Electrode Regulator Control Module for Electric Arc Furnace Automation
| Place of Origin | Shaanxi, China |
|---|---|
| Brand Name | Shaanxi Chengda |
| Certification | ISO9001 |
| Model Number | EAF-DCS-ERM |
| Minimum Order Quantity | 1 Set |
| Price | Price and specific model specifications can be agreed upon. |
| Packaging Details | Anti-static bag and export-grade wooden case |
| Delivery Time | 2 months |
| Payment Terms | L/C,D/A,D/P,T/T,Western Union, |
| Supply Ability | 50 Sets per Month |
Product Details
| Module Type | Electrode Regulator Control Module | Regulator Loop | Closed-loop Electrode Positioning |
|---|---|---|---|
| Output Signal | 4-20 MA / Servo Valve Output | Input Channels | 16 AI / 16 DI |
| Communication | DCS Fieldbus Interface | Operating Voltage | 24V DC |
| Redundancy | Hot Standby Compatible | Application | Electric Arc Furnace (EAF) Automation |
| Highlight | DCS electrode regulator module,electric arc furnace control module,furnace automation spare parts |
||
Product Description
DCS Electrode Regulator Control Module for Electric Arc Furnace Automation
The DCS electrode regulator control module provides precise closed-loop electrode positioning for electric arc furnace (EAF) automation. As a critical spare part of the distributed control system, it maintains stable arc power and improves melt quality across the whole smelting line.
Key Selling Points
- DCS Electrode Regulator Module: Dedicated control board designed for distributed control systems on electric arc furnaces.
- Hydraulic Electrode Positioning Unit: High-speed servo valve output drives the hydraulic electrode column with minimum overshoot.
- Arc Power Precision Control Spare: Fast closed-loop regulation holds constant arc impedance, cutting power consumption and electrode breakage.
Technical Highlights
- Closed-loop electrode regulation with anti-interference filtering
- Multi-channel analog and digital I/O for field sensors
- Standard fieldbus interface compatible with main DCS platforms
- Hot-standby ready for redundant control configurations
- DIN-rail mounted industrial grade module
Applications
Suitable for electric arc furnace, ferroalloy furnace and nonferrous metal smelting automation systems as a replacement spare part.
Contact us for compatibility confirmation and a quotation.
