60T AC Electric Arc Furnace Steelmaking 45MVA Transformer Water Cooled Roof Panel
| Place of Origin | Shaanxi, China |
|---|---|
| Brand Name | Shaanxi Chengda |
| Certification | CE, ISO 9001:2015 |
| Model Number | EAF-60AC |
| Minimum Order Quantity | 1 Set |
| Price | USD 850,000-1,200,000 / Set |
| Packaging Details | Standard export seaworthy packing with steel frame and moisture-proof wrapping |
| Delivery Time | 2 months |
| Payment Terms | T/T,L/C,Western Union |
| Supply Ability | 5 Sets per Year |
Product Details
| Furnace Type | AC Electric Arc Furnace | Rated Capacity | 60 Ton |
|---|---|---|---|
| Transformer Capacity | 45 MVA | Secondary Voltage | 380-680 V |
| Electrode Diameter | 500 Mm | Furnace Shell Diameter | 5600 Mm |
| Tap-to-Tap Time | 60 Min | Melting Rate | 35 T/h |
| Cooling Type | Water Cooled Roof And Panel | Application | Carbon Steel And Alloy Steel Melting |
| Highlight | 60T AC electric arc furnace steelmaking,45MVA transformer water cooled,steelmaking equipment roof panel |
||
Product Description
60T AC Electric Arc Furnace for Steelmaking
Our 60T AC electric arc furnace is a high-impedance, water-cooled steelmaking unit engineered for efficient melting of steel scrap and direct reduced iron. With a 45MVA transformer and optimized secondary voltage control, it delivers stable arc operation, low flicker and dependable tapping performance for modern steel plants.
Key Features
- High-impedance AC circuit reduces power consumption and extends refractory service life
- Water-cooled roof and wall panels improve thermal efficiency and shorten tap-to-tap time
- 45MVA furnace transformer with on-load tap changer for flexible melting control
- Hydraulic electrode regulation system keeps arc length and current stable
- Heavy-duty furnace shell with tilting platform for smooth slagging and tapping
- Complete PLC control with melt management and safety interlock functions
Technical Specifications
| Furnace Type | AC Electric Arc Furnace |
| Rated Capacity | 60 Ton |
| Transformer Capacity | 45 MVA |
| Secondary Voltage | 380-680 V |
| Electrode Diameter | 500 mm |
| Furnace Shell Diameter | 5600 mm |
| Tap-to-Tap Time | 60 min |
| Melting Rate | 35 t/h |
| Cooling Type | Water Cooled Roof and Panel |
Applications
Suitable for carbon steel and alloy steel melting in electric steelmaking shops, foundries and steel rolling plants. We provide complete electric arc furnace systems including transformer, ladle refining furnace, electrodes, water treatment and dust collection, with customized layout design and installation guidance.
Why Choose Us
With years of experience in metallurgical equipment, we supply EAF systems that meet international standards, supported by factory testing, on-site commissioning and operator training. Contact us for detailed drawings, capacity calculations and a quotation.
